introduction

Plenum rated fire retardant jacket is approved for installation in Plenum spaces


Features

  • MP/FT6 UL Rating: Fire retardant jacket is approved for installation in Plenum spaces
  • Active Optical Cable (AOC): Technology carries heavy TMDS HDMI channel over fiber
  • 4K/UHD Support: 4096x2160 or 3840x2160 50/60Hz at 4:4:4
  • 18 Gbps Bandwidth: High Speed / Performance for latest HDMI standards
  • High Dynamic Range (HDR) Format Support: HDR10 and Dolby® Vision
  • HDCP 2.2: Compliancy up to HDCP 2.2 and backward compliant
  • Ethernet Channel: 100 Mb/s Ethernet between two HDMI connecting devices
  • Audio Return Channel: Audio can be returned from display back to HDMI source for amplification and display
  • Deep Color Support: Up to 4K 24/25/30Hz 4:4:4/12 bits or 50/60Hz 4:2:0/12 bit
  • Directional Cable: Each head contains specific handling for optimal performance
  • OPEN EYE™ Technology: Certified & tested for 0% loss and noise-free performance
  • Support All Digital Audio Formats: Dolby® TrueHD, Dolby® Digital Plus, Dolby® Atmos and DTS-HD Master Audio™
  • Thin & Flexible: Wiring supports tighter bend radius than traditional HDMI
  • Powered by HDMI: No external powering

Additional Features

  • Pull Strength: Fiber Optic Cable = 33lb / 15kg. Connector = 53lb / 24kg

  • Cable Gage: 28 AWG
