Key Digital Unveils New Proprietary HDMI Extension Technology
KD-EX18G HDMI extension kit is the first Key Digital product boasting UHDoTP
MOUNT VERNON, NY – April 20, 2020 – Key Digital, the award-winning manufacturer of professional
AV and control systems introduces the new KD-EX18G HDMI extender kit featuring Key Digital’s new
proprietary HDMI extension technology, Ultra High Definition over Twisted Pair (UHDoTP).
The KD-EX18G with UHDoTP stands apart from other HDMI extenders as it allows Key Digital to present
this fully capable extender kit at a more cost-effective price point than most HDBaseT offerings. The KD-
EX18G features 4K/UHD 18G extension, 4K to 1080p down-conversion, HDMI pass-through, power over
CAT, two-way IR, handshake control, and Forced Hot Plug all in a low-profile slim chassis design.
“We are very excited to unveil our new proprietary Ultra High Def over Twisted Pair, or UHDoTP HDMI
extension technology. Key Digital is proud to continue the advancement of technologies that change the
applications and scope of AV products and installations, and UHDoTP is sure to be a game changer,” said
Masha Tsinberg Lakhter, COO of Key Digital. “We recognize the need for a range of features in one product
family and 4K to 1080p down-converting is a much anticipated benefit. The valuable KD-EX18G extender
kit checks so many boxes while remaining incredibly cost-effective. This is just the first Key Digital product
family to utilize UHDoTP, and we eagerly await its reception to the market.”
This new extender kit supports up to 18Gbps, meets HDCP2.2 compliancy, and extends video resolutions up
to 4096x2160 at 60hz with 4:4:4 chroma sub-sampling over a single CAT5e/6 cable up to 35m (115ft) and
1080p signals are extended up to 50m (164ft).
Providing added integration options in both new and retrofit instillations, the KD-EX18G features 4K to
1080p down-convert, which may be applied to the UHDoTP output. Using KD-EX18G in a Key Digital
matrix system, integrators may send signals from a 4K video source to a 1080p display without requiring the
4K source to lower its output resolution. When this feature is activated the integrator is benefited as the
signal may now be extended 50m (164 ft).
HDMI pass-through enables connection to local monitors or AV receivers for surround audio support of
Dolby®, Dolby® TrueHD, DTSTM and DTS-HDTM (formats up to 7.1). KD-EX18G features the unique
ability to copy the EDID handshake from the display or AV receiver connected to the HDMI pass-through
port as an alternative to copying from the display connected to the receive unit. When the afore mentioned
resolution down-conversion is applied, the HDMI pass-thru port remains active with the incoming 4K
signal.
The UHDoTP output on the KD-EX18G offers support of Dolby®, DTSTM (formats up to 5.1/6.1) and
extension with fully automatic adjustment of feedback, equalization, and amplification depending on cabling
length via a single CAT5e/6 cable. Visually lossless compression is achieved with 18G enabling technology
applied to all video formats exceeding 10.2Gbps to accommodate the UHDoTP transmission channel.
With flexible power over CAT (PoC) only one power connection is necessary. The transmitter may power
the receiver or the receiver may power the transmitter.
KD-EX18G features support of HDR10 (High Dynamic Range) video which allows users to experience
more life-like images through a greater range of luminance levels. Key Digital’s HDR10 delivery is handled
as part of their proprietary Full-Buffer System which manages TMDS re-clocking and signal re-generation,
HDCP authentication of source and display, EDID handshake control, and Hot Plug Detection control. The
KD-EX18G extender set delivers the highest possible support across the highly sought-after preferences of
video signals with both more contrast ratio and higher resolution. In 10G pass-through mode uncompressed
10.2Gbps signal extension is enabled.
Key Digital boasts an internal library with 15 EDID handshakes including an update to 4K handshakes
which includes HDR header information. Additionally, the native EDID data from the connected output/
display device may be provided to the video source. Three of the 15 EDID settings apply 4K to 1080p
down-conversion.
In addition to HDMI video and audio signals, KD-EX18G also carries IR for controlling remotely located
equipment. With IR sensor powering via +5V on IR In ports, KD-EX18G collects line-of-sight IR from
remotes without an external IR connecting block. Utilizing Up/Down IR, two channels of IR enable control
to and from devices or control systems connected to the transmitter and receiver units.
The KD-EX18G features deep color support up to UHD/4K 30Hz 4:4:4/12 bits or 60Hz 4:2:2/12 bit.
